1．Use：

Trinocular inverted optical microscope 4XC-V can be used to observe the surface of the organizational structure and form of operation to observe the surface of the sample downward, parallel with the work surface, so the height and shape of the sample has nothing to do for the larger sample and more convenient operation.    The instrument has the largest mobile stations and a variety of contents of the slide aperture, suitable for the operation of a larger sample; and it reflect coaxial external lighting system and easy to adjust optical path, insert the filter and more change light bulbs. With lift limit device with a focusing system, the specimen with the objective to avoid the bump, and the quantities do not have to repeat testing focus.

Metallographic Microscope System configuration in addition to high-definition image sensor cameras, and image processing systems, such as operating microscopes focusing simultaneously displayed in the display by the image processing system for real-time image processing, editing, storage and output (such as printing photos) or access to multimedia systems and e-mail.

    2. Specification:

1)  Eyepiece tube: Trinocular tube, eyepiece titled angel 30°,adjustable diopter, focus distance ajust range 53～75mm

2)  Eyepiece

3)  Objective、and Magnification

4)  Micrometer eyepiece 10×: flat-field value can zoom 0.1 mm grid5)  Micrometer scale: 0.01 mm L / 1 mm6)  Double mechanical loading Desk: 200×152 mm movement range of 15 ×15 mm7)  Focus: The coaxial coarse fretting movements limit the scope of the protection of 0.002 mm to

30mm fine-tuning8)  Lighting System: light filter with adjustable halogen 20W/6V9)  Objects magnification eyepiece and systems (Table)

10)  Object plate aperture: ф10mm   ф20mm

11) Filter: yellow,blue,green

12) Kohler lighting: halogen light continuously adjustable：12W/6V

13) Transfer: 220V/ Conitusely adjustable output power

14) Optional match system:

(1) Photograph device:

1. 135 film: 4×photograph eyepiece   135 camera box  Photographic format: 36mm×24mm
2. 120 dry plate: 10×photograph eyepiece 6×6 Monolithic box Photographic format: ф60mm

Photographic magnifications:

(2) Camera head:

Image suitable optical lens,   The camera image sensor（CCD）, Image Capture Card, Computers and printer

Imaging total magnifications: for referrance 1/3” CCD

(3) Digital photographic device:

Image suitable optical lens,   digital  camera, Image Capture Card, Computers and printer
